Series 5400 - Turn Switch

The Entech Series 5400 is a High Contact Density Family of turn switches. Either single or double sets of contact spring pile-ups may be mounted on both sides of the frame resulting in extensive circuit switching capability.

This frame assembly is available in either 45° or 90° maintained (latching) action. Optional enclosures include a metal or plastic dust cover with or without a plug connector. Please contact the factory for further details and the circuits that can be used with these enclosures.

Need a Push or Push-Pull version of this switch? Click here.

Some of the main features of the Series 5400 switch include:

»High density circuit capability - up to 20 independent A Form circuits per switch
»Contact ratings from dry circuit to 5 Amps at 125 VAC (resistive)
»Rugged brass frame with anti-pull-through bushing design
»Mounts in panels from .050" to .250" and a variety of Mosaic Grid & Tile Systems
»Optional bifurcated contacts available for redundancy in critical low voltage/cycle applications

Important information required to provide an accurate quote

1. Contacts required by basic form letter (A, B, etc.)
2. Location of the contacts on the switch by position, number and if on left or right side
3. Contact ratings (may be mixed on the same switch)
4. Button action - ALL actions are maintained, no momentary functions - SEE TABLE ABOVE

See the general characteristics of multiple contact switches page for more detailed information.
